Specifications
|
System |
PAL/NTSC |
|
Solution |
1/3"5510+FH8538M |
|
Effective Pixels |
2592*1944 |
|
Video output |
1.0Vp-p,75II Composite,BNCx1 |
|
Horizontal resolution |
5MP |
|
S/N Ratio |
>52dB(AGC OFF/BW OFF) |
|
illumination |
0.001Lux |
|
Minimum illumination |
0.0001 Lux(IR ON) |
|
Electronic Shutter |
1/50-1/10,0000S |
|
White Balance |
Auto |
|
Gamma Ratio |
>=0.45 |
|
Color of camera housing |
white |
|
Infrared |
36PCS IR LED |
|
IR Distance |
30Meter IR Distance |
|
Infrared Wavelength |
850nm |
|
Waterproof |
N/A |
|
Lens Mount |
2.8-12mm Varifocal lens |
|
Operating Temperature |
Indoor:-10C to 50C |
|
Humidity |
0 to 95% RH(non-condensing) |
|
Sync system |
2:1 interlace internal Sync. |
|
Power supply |
12V DC |
