Specifications
| System |
PAL/NTSC |
|
Solution |
OV12895+ FH8556H (1/2.3” CMOS Sensor) |
|
Effective Pixels |
8.0MP PAL: (3840*2160)@15fps, NTSC: (3840*2160)@15fps |
|
Video output |
1.0Vp-p, 75II Composite, BNC x 1 |
|
Horizontal resolution |
3840X2160 |
|
S/N Ratio |
>52dB（AGC OFF/BW OFF） |
|
illumination |
0.001 Lux |
|
Minimum illumination |
0.001 Lux @ (F1.2,AGC ON),0 Lux with IR |
|
Electronic Shutter |
1/50 - 1/10,0000S |
|
White Balance |
Auto |
|
Gamma Ratio |
≥ 0.45 |
|
Color of camera housing |
White |
|
Infrared |
18PCS SMD LED |
|
IR Distance |
30Meter IR Distance |
|
Waterproof |
N/A |
|
Lens Mount |
3.6MM 8MP LENS |
|
Operating Temperature |
Indoor: -10℃ to 50℃ |
|
Humidity |
0 to 95% RH (non-condensing) |
|
Sync system |
2:1 interlace internal Sync. |
|
Power supply |
12V DC |
