Specifications
|
Lens |
FH8536(V30)+AR0237 1080P 4 in 1, 3.5-10.5mm Sync-focus lens,ICR |
|
Resolution |
1080P (1920x1080) |
|
Frame |
25/30 fps |
|
OSD |
Support |
|
Communication |
Control over coaxial & RS485 |
|
Max. IR LEDs Length |
40m |
|
Manual speed |
Pan（0.2°～80°/s）; Tilt（0.2°～50°/s） |
|
Preset speed |
80°/s |
|
Rotation |
Continuously 360°；tilt 0～90° with auto-flip |
|
Power up Action |
Auto restore to previous PTZ and lens status after power failure |
|
Idle Motion |
Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period |
|
Time task |
Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time |
|
Preset |
128 preset, title can be edited |
|
Auto-flip |
Tilt down 90°, with auto-flip 180° |
|
Pattern |
4 pattern, time and speed can be set |
|
Video output |
Female BNC |
|
Baud rate (RS485) |
2400／4800／9600/19200 bps |
|
ID range |
1～254 |
|
Protocols |
Pelco D/P self adaptor |
|
Temperature |
-10℃～+50℃ |
|
Humidity |
0～95%（Non-condensation） |
|
Protection grade |
lighting-proof, surge-proof |
|
Power Supply |
DC12V |
|
Power consumption |
＜6W |
|
Net weight |
1.1 kg |
