Specifications
|
Optical zoom |
NXT2441H+IMX323 CMOS 2.0MP 5.1-51mm 10x, 0.1Lux/F1.67 Color; / 0.05 Lux/F1.67 B/W H: Appr. 64°(W) ~7.3°(T) / V:Appr. 39.1°(W) ~4.4°(T) |
|
Interface |
BNC |
|
Max Imagine Resolution |
1920*1080p |
|
Frame |
25/30 fps |
|
OSD |
Support |
|
Communication |
Control over coaxial & RS485 |
|
Protocols |
Pelco D/P self adaptor |
|
Manual speed |
Pan（0.2°～200°/s）; Tilt（0.2°～150°/s） |
|
Preset speed |
200°/S |
|
Rotation |
Continuously 360°；tilt 0～90° with auto-flip |
|
Speed Proportion |
Human-oriented focal length/speed adaptation |
|
Preset |
128 preset, title can be edited |
|
Auto-flip |
Tilt down 90°, with auto-flip 180° |
|
Scan |
355° programmable , 4 scan |
|
Pattern |
4 patterns, time and speed can be set |
|
Power up Action |
Auto restore to previous PTZ and lens status after power failure |
|
Idle Motion |
Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period |
|
Time task |
Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time |
|
Decoder |
Built-in |
|
Baud rate (RS485) |
2400／4800／9600/19200 bps |
|
Temperature |
10℃～+50℃ |
|
Humidity |
0～95%（Non-condensation） |
|
Protection grade |
1500v lightning-proof, surge-proof |
|
Power Supply |
DC12V |
| Net Weight | 1.5kg |
