Specifications
System |
|
|
OS |
Embedded Linux |
|
Compression |
Standard H.265 High Profile |
Video |
|
|
Analog Input |
BNC × 16 |
|
Resolution |
TVI/AHD : 8MP/5MP/4MP/3MP/1080P/720P/WD1 CVI : 4MP/3MP/1080P/720P/WD1 |
| IP Input | 8CH (Up to 16CH) |
|
Output |
HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 BNC × 1 : CVBS ( used as the main or spot output ) |
Audio |
|
|
Input |
RCA x 1 |
|
Output |
RCA × 1 |
|
Two-way audio |
Take up channel one audio input |
Record |
|
|
Frame Rate |
4K@6/7fps (PAL/NTSC) 4K Lite@12fps/15fps (PAL/NTSC) 5MP@12fps (PAL / NTSC) 5MP Lite@20fps (PAL / NTSC) 4MP@12fps(PAL) / 15fps (NTSC) 4MPLite/1080P/720P/WD1@25fps (PAL) / 30fps (NTSC) |
|
Resolution |
4K/4K Lite/5MP/5MP Lite/4MP/4MP Lite / 1080P/ 720P/WD1/D1 |
|
Bit Rate |
32Kbps ~ 5Mbps |
|
Mode |
Manual, timer, motion |
IP Input |
|
| Resolution | 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P |
|
Frame Rate |
25fps ( PAL ) / 30fps ( NTSC ) |
Playback |
|
|
Playback |
16 CH |
|
Search |
Time slice / time / event / tag search |
|
Smart Search |
Highlighted color to display the camera record in a certain period of time, different colors refers to different record evwents |
|
Function |
Play, pause, FF, FB, digital zoom, etc. |
Alarm |
|
|
Mode |
Manual, motion, exception |
|
Input |
No |
| Output | No |
|
Triggering |
Record, snap, preset, e-mail, etc |
Network |
|
| Interface |
RJ 45 100Mbps × 1 |
|
Protocol |
TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP |
|
Bandwidth(MbpS) |
64/192 (access/transfer) |
Mobile Device |
|
| OS |
iOS, Andriod |
Storage
|
|
| HDD |
SATA × 2, up to 8TB per HDD |
Backup |
|
|
Local Backup |
U disk, USB mobile HDD |
|
Network Backup |
Yes |
Port |
|
|
RS 485 |
RS485 × 1, connect to PTZ or keyboard |
|
USB |
USB 2.0 × 2 |
|
Remote Controller |
Optional |
Others |
|
|
Power Supply |
ATX-250W |
|
Consumption |
≤ 30W ( without HDD) |
|
Dimensions（mm） |
440 × 390 × 70( W × D × H ) |
|
Working Environment |
-10 ～ 50 ℃，10% ～ 90% humidity |
