Specifications
Camera |
|
|
Image Sensor |
1 / 1.8 "progressive scan CMOS |
|
Effective Pixels |
2048 × 1536 |
|
Horizontal Resolution |
1300 TVL |
|
Min. Illumination |
0 Lux |
| IR Distance |
100m |
|
White Balance |
Auto/ Manual |
| WDR | 120dB |
|
S / N Ratio |
Max 48dB |
|
Day / Light |
Auto / Manual |
|
Focus Mode |
Auto/Manual |
|
Lens |
20× Zoom, f = 5.5 ~ 110 mm, F1.6 ~ F3.5 |
PTZ |
|
|
Pan Range |
360° endless rotation |
|
Pan Speed |
Preset speed : 150 °/ s; Manual control speed : 0.5 ~ 80 °/s |
|
Tilt Range |
0 ~ 93° ( auto rotation ) |
|
Tilt Speed |
Preset speed : 120 °/ s; Manual control speed : 0.5 ~ 70 °/s |
System |
|
| PTZ Control |
Yes |
|
Preset |
360 |
| Cruise | 8 |
|
Track |
4 |
| Time Task |
8 |
| Scan | 2 |
|
Home Position |
Yes |
|
Auto Flip |
Yes |
|
OSD Menu |
English |
|
Alarm Input |
1 |
|
Alarm Output |
1 |
|
Alarm Linkage |
Yes |
Network |
|
| Compression | H.265 |
| Frame Rate | 1 ~ 30fps ( 25 fps ) |
|
Protocol |
TCP / IP, UDP, DHCP, DDNS, NTP, RTSP, SMTP, FTP, PPPoE |
|
Storage |
SD card local storage, network remote storage |
|
Smart Alarm |
Motion Alarm, Sensor Alarm |
| Resolution |
3MP (2048 1536 ), 1080P ( 1920 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240 |
|
Multi-stream |
Yes |
Port |
|
|
Network Interface |
10 Base-T / 100 Base-TX, RJ45 |
|
Audio |
MIC input × 1, MIC output × 1 |
Others |
|
|
Control |
Network |
|
Power Supply |
DC 24V / 2500 mA |
| Power Consumption | 15 W ( max 30W, IR on ) |
|
Working Environment |
Temperature : - 30 °C ~ 60 °C; Relative humidity : less than 95% |
| Protection Level |
IP66&IK10; TVS 6KV lightning protection, surge protection |
| Net Weight |
3.77KG |
| Gross Weight |
5.83KG (without bracket) |
| Dimensions ( mm ) |
Φ 209 × 317 |
