Specifications
System |
||
| Compression | Standard H.265, H.264 | |
| OS |
Embedded Linux |
|
Video |
||
|
Model |
QVN3104 |
QVN3108 |
|
Network Input |
4 CH IPC input |
8 CH IPC input |
|
IP Input Access / Transfer Bandwidth |
32Mbps / 32Mbps |
56Mbps / 56Mbps |
|
Network Access Format |
6MP/5MP/4MP/3MP/1080P/960P/720P@25 / 30fps |
|
|
Output |
HDMI × 1 : 1920×1080/1280×1024/1024×768 VGA × 1 : 1920×1080/1280×1024/1024×768 |
|
Audio |
||
|
Model |
QVN3104 |
QVN3108 |
|
Network Input |
4 CH IPC audio input |
8 CH IPC audio input |
|
2-way Audio |
No |
|
|
Local Output |
No ( HDMI supports the audio output ) |
|
Record |
||
|
Model |
QVN3104 |
QVN3108 |
|
Record Stream |
Dual stream recording |
|
|
Resolution |
6MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P @25 / 30fps |
|
|
Mode |
Manual, timer, motion, sensor, smart events |
|
Playback |
||
| Model |
QVN3104 |
QVN3108 |
|
Simultaneous Playback |
Max 4 CH |
Max 8 CH |
| Search |
Time slice / time / event / tag search |
|
|
Smart Search |
Highlighted color to display the camera record in a certain period of time, different colors refers to different record events |
|
|
Function |
Play, pause, FF, FB, digital zoom, etc. |
|
Alarm |
||
| Model |
QVN3104 |
QVN3108 |
| Mode |
Manual, sensor, motion, exception |
|
| Input |
No |
|
| Output | No | |
|
Triggering |
Record, snap, preset, e-mail, etc. |
|
Network |
||
| Model |
QVN3104 |
QVN3108 |
|
Interface |
RJ45 100 Mbps × 1 |
|
|
Protocol |
TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP |
|
Mobile Device |
|
|
| OS |
iOS, Andriod |
|
Storage |
||
|
HDD |
SATA × 1, up to 6TB per HDD |
|
Backup |
||
|
Local Backup |
U disk, USB mobile HDD |
|
|
Network Backup |
Yes | |
Port |
||
| USB |
USB 2.0 × 2 |
|
|
Remote Controller |
Optional | |
Others |
||
|
Power Supply |
DC12V/1.5A |
|
|
Consumption |
≤ 6W ( without HDD ) |
|
|
Dimensions（mm） |
255 × 233 × 42 ( W × D × H ) |
|
|
Working Environment |
-10 ～ 50 ℃，10% ～ 90% humidity |
|
