Specifications
| Video | |
| System | High performance NVP2431H ISP processor |
| Sensor | 1/3" CMOS Sensor |
| Output resolution | 1.3 MP :1280(H)×960(V) |
| D/N Mode | IR cut Auto switching |
| Minimum Illumination | 0.00LUX/F1.2(Led on) |
| Effective Pixel | PAL : 1280*960@25fps; NTSC : 1280*960·30fps |
| Signal System | PAL/NTSC |
| Video Standard | AHD and CVBS Standard |
| Video Output | 1CH AHD HD/CVBS Standard Singal Output(Switchable) |
| Max Transmission Distance | 75-5 cables can be up to 500m |
| Lens and IR | |
| Lens | 130° Wide Angle lens |
| IR distance | 15pcs IR LEDs,10-15meter night vision |
| Common | |
| Shutter Speed | 4/25s-1/45,000s |
| BLC | Off/Low/Medium/High/Highest |
| White Balance | Auto White Balance |
| Operation Temperature | -10°C~55°C |
| Power Supply | DC12V |
| Dimension | Φ105*80.8 |
| Operating Temperature | -10°C~55°C |
| Dimension | Φ105*80.8 |
| Weight | 0.38Kg |
