Specifications
| System | |
| Compression | H.265/H.264 |
| OS | Embedded Linux |
| Video | |
| Local Input | RS485 × 2, connect to PTZ or keyboard |
| Resolution |
USB 2.0 × 1 , USB 3.0 × 1 ( one in the front panel and the other in the rear panel ) |
| Network Access Format | Up to 8MP |
| Output | HDMI×2：one of 4K × 2K / 1920 ×1080/ 1280 ×1024 the other of 1920 ×1080/ 1280×1024 |
| IP Input | Yes |
| Total Input | 32 CH |
| Output |
HDMI1:3840×2160/1920×1080/1280×1024 HDMI2 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA : 1920 × 1080 / 1280 × 1024 BNC × 1 : CVBS ( used as the main or spot output ) |
| Audio | |
| Input | RCA × 16 (2.0Vp-P, 1kΩ) |
| Output | RCA × 1(linear, 600Ω) |
| Two-way audio | RCA × 1 |
| Compression | G.711A/U |
| Record | |
| Resolution |
8MP/8MP Lite/ 5MP/5MP Lite/4MP/4MP Lite / 3MP/ 1080P/720P/WD1/D1 |
| Frame Rate |
Analog channels: 8MP@8fps (PAL/NTSC) 8MP Lite @12fps/15fps (PAL/NTSC) 5MP@12fps (PAL / NTSC) 5MP Lite@20fps (PAL / NTSC) 4MP/3MP@12fps(PAL) / 15fps (NTSC) 4MPLite/1080P/720P/WD1/D1@25fps / 30fps (PAL/NTSC) IP channels: up to 8MP @30fps |
| Bit Rate | 32Kbps ~ 10Mbps |
| Mode | Manual, timer, alarm linkage |
| IP Input | |
| Resolution | Up to 8MP |
| Frame Rate | 25fps ( PAL ) / 30fps ( NTSC) |
| Playback | |
| Playback | 16 CH |
| Decoding Capability |
1 CH 8MP 16CH 1080P@30fps |
| Search | Time slice / time / event / tag search/smart search |
| Smart Search |
Highlight colors to display the camera record in a certain period of time,different colors refer to different record events |
| Function | Play, pause, FF, FB, digital zoom, etc. |
| Alarm | |
| Input | 16 CH |
| Output | 8 CH |
| Triggering | Record, snap, preset, e-mail, buzzer, etc. |
| Network | |
| Interface | RJ 45 1000Mbps × 2 |
| Protocol |
TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, ONVIF |
| Bandwidth | 160/320Mbps (incoming/outgoing) |
| Mobile Device | |
| OS | iOS, Andriod |
| Storage | |
| HDD | SATA × 8, up to 8TB per HDD; |
| E-SATA | Yes |
| RAID | RAID 0, 1, 5, 6, 10 |
| Backup | |
| Local Backup | USB flash disk, USB mobile HDD |
| Network | Yes |
| Backup | Yes |
| Port | |
| RS 485 | RS 485 × 2, connectors for PTZ and keyboard |
| USB | USB 2.0 × 2; USB3.0× 1 |
| Remote Controller | Optional |
| Others | |
| Power Supply | ATX 250W |
| Consumption | ≤ 70W ( without HDD ) |
| Dimensions(mm) | 445 × 436× 90 ( W × D × H ) |
| Working Environment | -10~50°C, 10%~90% (humidity) |
