Specifications
Camera |
|
| Image Sensor | 1 /2.7" COMS |
|
Image Size |
3840 × 2160 |
|
Electronic Shutter |
1 / 25 s ~ 1 / 100000 s |
|
Iris Type |
Fixed Iris |
|
Min. Illumination |
0.11 lux @F2.2, AGC ON; 0 lux with IR 0.032 lux @ F1.2, AGC ON; 0 lux with IR |
|
Lens |
2.8~12mm@F1.4, (motorized zoom lens) , horizontal field of view: 102.7°~32.2° |
|
Lens Mount |
M12 or Φ14 optional |
|
Wide Dynamic Range |
Digital WDR |
|
BLC |
Yes |
|
HLC |
Yes |
|
Defog |
Yes |
|
Digital NR |
3D DNR |
|
Angle Adjustment |
Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360° |
Interfaces |
|
|
Network |
RJ45 |
|
Audio |
1CH audio input |
|
Storage |
Built-in micro SD card slot; up to 128GB |
|
Hardware Reset |
Yes |
|
Video Output |
No |
Functions |
|
|
Remote Monitoring |
Web browsing, CMS remote control |
|
Interface Protocol |
ONVIF |
|
Storage |
Network remote storage, micro SD card storage |
|
PoE |
Yes |
|
Online Connection |
Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission |
|
Network Protocol |
UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP 802.1x, UPnP, HTTP, HTTPs, QoS |
|
Smart Alarm |
Motion detection, SD card error, SD card full |
|
General function |
Watermark, IP address filtering, video mask, heart beat, illegal login lock |
|
IR Distance |
30 ~ 50 m |
|
Ingress Protection |
IP67 |
|
Intelligent Analytics |
Region intrusion detection, scene change detection and line crossing detection |
Image |
|
|
Video Compression |
H.265 / H.264 |
|
H.264 Compression Standard |
Baseline Profile/Main Profile/High Profile |
|
Resolution |
8MP ( 3840 × 2160 ), 6MP ( 3072× 2048 ), 5MP ( 2592 × 1944 ),720P ( 1280 × 720 ), D1, CIF, 480 × 240 |
|
Main Stream |
8MP/ 6MP/ 5MP(1~20fps) |
|
Sub Stream |
720P/D1/CIF(1~20fps) |
|
Third Stream |
D1/CIF/480x240(1~20fps) |
|
Bit Rate |
64 Kbps ~ 8 Mbps |
|
Bit Rate Type |
VBR / CBR |
|
Audio Compression |
G711A / U |
|
Image Settings |
ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser |
|
ROI |
Each ROI to be configured separately |
Others |
|
|
Power Supply |
DC12V / PoE |
|
Power Consumption |
< 9.5W |
|
Dimensions ( mm ) |
217.7 × 80.5 × 80.5 |
|
Operating Environment |
-30 °C ~ 60 °C (-22°F~140°F); Humidity: less than 95 % (non-condensing) |
|
Weight ( net ) |
Approx. 0.66KG |
|
Installation |
Ceiling mounting; Wall mounting |
