Specifications
|
System |
PAL/NTSC |
|
Solution |
CMOS 7640+V20E |
|
Effective Pixels |
1280(H)*720(V) |
|
Video output |
1.0Vp-p, 75II Composite, BNC x 1 |
|
Horizontal resolution |
720P |
|
S/N Ratio |
>52dB（AGC OFF/BW OFF） |
|
illumination |
0.001 Lux |
|
Minimum illumination |
0.000 Lux(IR ON) |
|
Electronic Shutter |
1/50 - 1/10,0000S |
|
White Balance |
Auto |
|
Gamma Ratio |
>=0.45 |
|
Color of camera housing |
Dark gray |
|
Infrared |
36PCS IR LED |
|
IR Distance |
30Meter IR Distance |
|
Infrared Wavelength |
850nm |
|
Waterproof |
IP66 |
|
Lens Mount |
2.8 lens |
|
Operating Temperature |
Outdoor: -10C to 50C |
|
Humidity |
0 to 95% RH (non-condensing) |
|
Sync system |
2:1 interlace internal Sync |
|
Power supply |
12V DC |
