Specifications
Camera |
|
|
Image Sensor |
Four 1 / 2.8 " Progressive Scan CMOS |
|
Resolution |
1920×1080 |
|
Image System |
PAL/ NTSC |
|
Iris Type |
Fixed Iris |
|
Minimum Illumination |
Color:0.1 lux@(F2.1,AGC ON ), 0 lux with IR |
|
Electronic shutter |
PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
|
Lens |
4mm |
|
IR LEDs |
2PCS 3600K soft warm light |
|
SNR |
＞52dB (AGC off) |
|
IR distance |
20m |
|
Video Frame Rate |
1080P@25fps, 1080P@30fps |
|
Video Output |
1HD TVI/AHDCVI/CVBS output |
Menu |
|
|
D&N |
Support ICR EXT/Auto / Color/ BW (Black and White) |
|
DNR |
Support 2D 3D NR |
|
WDR |
DWDR |
|
Smart LED |
Support Auto/Manual model,brightness can adjustable |
|
White Balance |
ATW / MWB |
|
BLC |
Support |
|
Image set |
contrast、sharpness、saturate、3DNR、2DNR、DWDR |
|
Language |
English, Chinese |
General |
|
|
Power Supply |
12VDC ± 10 %; |
|
Operating Conditions |
Humidity 90% or less (-20° C to 60° C) |
|
Protection level |
Condensing IP66 |
|
Power Consumption |
Max. 5W (Max. 5W with IR cut filter on) |
|
Dimensions |
154mm*71mm*71mm |
