Specifications
|
Image sensor |
1/3" OmniVision CMOS Sensor OV4689 |
|
Signal System |
PAL/NTSC |
|
Effective Pixel Array |
2688（H）*1520（V） |
|
Horizontal resolution |
1500TVL |
|
IR Led |
36pcs IR Leds |
|
IR Distance |
Up to 100ft |
|
Lens |
Fix lens 3.6mm |
|
S/N Ratio |
More than 60dB |
|
Power Supply |
12 VDC±15% |
|
Min. Illumination |
0.01 Lux @ (F1.2,AGC ON), 0 Lux with IR |
|
Electronic Exposure |
1/25(1/30) s to 1/50,000 s |
|
AGC |
Auto |
| White Balance |
AWB/AWC |
|
BLC |
BLC/HLC/OFF |
|
Video Output |
1 Analog HD output |
|
IR Wave Length |
850nm |
|
IR LED Auto Switch |
Day/Night, On/Off |
|
Camera stand |
Wall |
|
Power Consumption |
Max 1w |
|
Waterproof Rate |
Ip66 |
|
Operating Temperature |
(-10 ~ 60 °C ) RH 95％Max |
|
Dimension |
170.8(L) *65(W) *64.3(H) mm |
|
Weight |
500g |
