Specifications
Camera |
|
|
Image Sensor |
1/2.9” 2MP Progressive Scan COMS |
|
Resolution |
2560*1920 |
|
Image System |
PAL/NTSC |
|
Minimum Illumination |
Color: 0.1 lux @ (F2.1, AGC ON), 0 lux with IR |
|
Electronic shutter |
PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
|
Lens |
3.6mm |
|
LEDs |
2 PCS 3500K soft warm light |
|
SNR |
>52dB（AGC off） |
|
Full color distance |
15m |
|
Video Frame Rate |
20fps |
|
Video Output |
TVI/AHD/CVI/CVBS |
Menu |
|
|
D&N |
Support ICR EXT/Auto / Color/ BW (Black and White) |
|
DNR |
Support 2D 3D NR |
|
WDR |
DWDR |
|
Smart LED |
Support Auto/Manual model,brightness can adjustable |
|
White Balance |
ATW / MWB/GRAY WORLD |
|
BLC |
Support |
|
Image enhance |
contrast、sharpness、saturate、3DNR、2DNR、DWDR |
|
Language |
English, Chinese |
General |
|
|
Power Supply |
12VDC ± 10 %; |
|
Operating
Conditions |
Humidity 90% or less (-20° C to 60° C) |
|
Protection level |
Condensing IP66 |
|
Power
Consumption |
Max. 5W(Max. 5W with IR cut filter on) |
|
Dimensions |
154mm*71mm*71mm |
