Specifications
| Model | QVP21W |
| Compression | H.264/H.265 |
| Image Sensor | 1/2.7” 2Megapixel progressive CMOS |
| Effective Pixels | 1920(H) x 1080(V) |
| Scanning System | Progressive |
| Minimum Illumination | 0.1Lux/F2.0(Color), 0Lux/F2.0(IR on) |
| IR Distance | 1PC up to 10m |
| Warning Light | 1 |
| Lens | 2.8mm,F 1.85±10% |
| Angle of View | H:103° |
| Pan/Tilt Range | Pan:0° ~360° ;Tilt:-10° ~90° ;Rotation:0° ~360° |
| Streaming Capability | 2 Streams |
| Resolution | 1080P(1920×1080)/1.3M(1280×960)/ |
| 720P(1280×720)/VGA(640 ×480)/ | |
| QVGA(320×240) | |
| Frame Rate | 1080P(1~25fps) |
| VGA/QVGA(1~25fps) | |
| Bit Rate | 8K ~ 8Mbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC Mode | BLC / DWDR |
| White Balance | Auto/Outdoor/Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off / On |
| Smart IR | Support |
| Privacy Masking | Off / On (4 Area, Rectangle) |
| Compression | G.711 |
| Ethernet | RJ-45 (10/100Base) |
| Wi-Fi | 2.4GHz & 5GHz Wi-Fi(IEEE802.11a/b/g/n/ac) 10m |
| Protocol |
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP,UPnP,SNMP,HTTPS,FTP, |
| Streaming Method | Unicast |
| Max. User Access | 10 Users |
| Edge Storage | Micro SD Card (up to 128GB) |
| Local PC for instant recording | |
| Smart Phone | iOS, Android |
| Audio Interface | Built-in Mic & Speaker |
| Alarm | 1/1,PIR |
| Power Supply | DC12V/POE |
| Power Consumption | ≤3W |
| Operating Conditions | -10°C ~ +45°C (14°F ~ +113°F) / Less than 95% RH |
| Strorage Conditions | -10°C ~ +45°C (14°F ~ +113°F) / Less than 95% RH |
