Specifications
| Image Sensor | 1/3" OmniVision CMOS Sensor OV4689 |
| Signal System | PAL/NTSC |
| Effective Pixel Array |
2688（H）*1520（V） |
| Horizontal resolution |
1500TVL |
|
IR Led |
30pcs IR Leds |
|
IR Distance |
Up to 100ft |
|
Lens |
Fix Lens 3.6mm |
| S/N Ratio |
More than 60dB |
| Power Supply | 12 VDC±15% |
| Min. Illumination | 0.01 Lux @ (F1.2,AGC ON), 0 Lux with IR |
| Electronic Exposure | 1/25(1/30) s to 1/50,000 s |
|
AGC |
Auto |
|
White Balance |
AWB/AWC |
| BLC | BLC/HLC/OFF |
| Video Output | 1 Analog HD output |
| IR Wave Length |
850nm |
| IR LED Auto Switch | Day/Night, On/Off |
| Camera stand | Wall |
| Power Consumption | Max 1w |
|
Waterproof Rate |
IP66 |
|
Operating Temperature |
(-10 ~ 60 °C ) RH 95％Max |
|
Dimension |
97(L) *97(W) *63(H) mm |
|
Weight |
500g |
